Round 2 for the 2019 Formula 1 season and we’re in Bahrain for what could be a wonderful race weekend and before we start featuring press conferences and driver interviews, you can see some of the challenges which the Mercedes-AMG Petronas are looking out for ahead of the weekend….

What kind of temperatures can we expect in Bahrain?

In past years, we have seen the air temperatures climb up to 38 degrees celsius (and more) in the middle of the day – with the track temperatures creeping up to the mid and high 50’s!

Whilst we do see extremely high temperatures in the middle of the day, both the track and ambient temperature tends to cool down significantly when the sun sets.

As we’ve mentioned, FP2, Qualifying and the race all take place at 18:00 local time – those sessions tend to be much more comfortable conditions with the outside temperatures being in the mid-to-high 20’s or low 30’s with the track temperature being mid 30’s.

The year however, the temperatures are forecast to be a little bit cooler – with even some light rain predicted in the days leading towards the weekend…

How do F1 cars react to high temperatures?

There’s a number of things which can go wrong or react due to the high temperatures, particularly the Power Unit, the gearbox and the electrical systems, which would sustain damage if the team was to run them above their temperature limits for prolonged periods of time.

So, when the W10 is run in a hot climate, the team has to open up the bodywork of the car for additional cooling in order to prevent those components from overheating. However, opening up the bodywork means losing aerodynamic performance as the additional air inlets produce drag and also disturb the air flow around the car, negatively impacting the efficiency of the rear wing and the diffuser.

Depending on which aero configuration the team runs, the difference in lap time can be quite substantial; a completely closed-up car would be several tenths of a second per lap faster compared to one that is opened up for maximum cooling.

Can the teams run a different cooling configuration in Qualifying and the race?

Yes and no.

The regulations specify that F1 teams have to start the race with the same cooling configuration which they ran in Qualifying, meaning that the cooling can’t be changed in Parc Ferme. However, the bodywork can potentially be opened up during a pit stop, should the sensors on the car indicate that certain components are running hot.

One area that is relatively easy to open up is a cooling panel below the headrest area. The louvers in that panel can be covered up for Qualifying and the first stint, with the cover easily removable in a pit stop to add another three to five percent of extra cooling for the second stint.

FP1 and FP3 take place in the heat of the day; FP2, Qualifying and the Race take place in the cooler temperatures of the evening. What implications does that have?

The change in ambient conditions between the sessions means that the amount of representative running is limited. FP2 is the only practice session with similar conditions to the race, so the teams will focus on their race programmes on Friday evening.

While the heat of FP1 might not be ideal for doing long-run simulations, the session is still useful to work on other items.

Teams might test new parts or work on their understanding of the 2019 tyres, knowing that the hot conditions are harsh on the tyres and lead to quick degradation and rear overheating.

The first session on Saturday is usually devoted to single-lap performance with the drivers doing a lot of cool down laps to get the tyres back into the temperature window for the start of the next lap.

How useful is the data from FP1 and FP3 for the rest of the weekend?

While the majority of the race preparation is conducted in FP2, teams can still do a bit of set-up work in the hot sessions.

It’s crucial to not to get misled by the big swings; so the teams have to be extra careful to make the right adjustments to the balance of the car, so that the cars are not tuned for the wrong conditions.

Are there any other circumstances that make racing tricky in Bahrain?

The Bahrain International Circuit is located on a former camel farm in a rural and flat area, surrounded by desert and sand, with winds easily sweeping sand onto the track. When Formula One first came to Bahrain, engineers were wondering if the sand might have a detrimental effect on the car, the systems and if they might need special filters to keep the sand out.

Today, 15 years later, we know that no special filters are required; however, the sand does have an abrasive effect, which has a negative impact on the aero surfaces.

That being said, the track does clean up relatively quickly though. Once 20 cars have gone by, the tarmac is in a much better condition and this means the biggest impact of the sand is to the start of the sessions, as it can create a bit of a standoff as the teams all wait for others to go out and clean the track.
